Delfzijl Repeater Group
PI6NLT 10m repeater system information ...
Copyright © 2008 by
"PE2AWT"
All Rights reserved
   QTH receiver:
  Receiver:
Frequency:
Modulation:
Sensitivity:
Antenna:
Polarisation:
CTCSS:
Access:
Control logic:
Distance RX-TX:
Connection RX-TX:
Link-transmitter:
Link-antenna:
Delfzijl, JO33KH (20m ASL)
Yaesu FT-8900
29.540 MHz
F3E (FM)
0,08 uV with CTCSS
Solarcon MAX 2000 5/8-wave
vertical (Omni-directional)
82.5 Hz (turns off the squelch treshold)
carrier (minimum 2 seconds)
homemade
2 km
1.2 GHz radiolink
Kenwood TM-531 (1 Watt)
10 turn helix
QTH transmitter:
Transmitter:
Frequency:
Modulation:
RF-output:
Antenna:
Polarisation:
Control logic:
Timeout:
Distance TX-RX:
Connection TX-RX:
Link-receiver:
Link-antenna:
Farmsum, JO33KH (18m ASL)
Yaesu FT-8900
29.640 MHz
RH3
25 Watt
Solarcon MAX 2000 5/8-wave
vertical (Omni-directional)
Echostation by K1RFD
10 minutes
2 km
1.2 GHz radiolink
Kenwood TM-531 (1 Watt)
Diamond X-4000
Channel:
Channel:
RH3
F3E (FM)
Squelch-Treshold:
0,25 uV without CTCSS
